Hello and welcome to EZ Turn Signal Kits
|
|
|
|
|
|
|
Hello, my name is Cisco Folk and I am the President of EZ Website Builders here in Glendale, AZ. My passion is the outdoors and I purchased a 2006 Polaris Ranger to help me get around. After a few years of using the old, hang your arm out the side to signal on coming traffic, I decided I had enough. I wanted to install LED turn signals for my added safety. When I tried to purchase the LED turn signals, I was unable to find anyone who had a 4 LED Turn Signal Kit. I found one that was 4 regular bulbs and another that was 2 LED's and 2 regular bulbs. But, as we all know the UTV's have small batteries and low charging systems. The main reasons why I wanted all 4 turn signal lights to be LED are:
- Less current draw, resulting in increased battery & alternator life while allowing more power for other vehicle requirments.
- Faster illumination offers significant safety benefits for following drivers to react quicker, resulting in an average of three foot reaction time advantage for every 10 miles per hour.
- LEDs have no filament, therefore are not susceptible to shock & vibration, a major cause of failure for lamps with incandescent bulbs.
|
|
|
So, I created my own LED Turn Signal Kit. I wanted good looking, clean and crisp LED lights, ones that were very visible, even during the day. The LED Lights in my kit are not only 16 light emitting diodes each, but they are hard wired with encapsulated electronics to eliminate corrosion. They have both the black (+) and white (-) wires to make a great connection, no screw through a metal surface to the frame for ground. You can hard wire the lights to both positive and ground, so you always have a great connection.
|
|
|
|
|
The Turn Signal Switch is heavy duty, has the right and left turn signals along with a pull out flare tab for the 4-way emergency (hazard warring) flashers. I added an 18" black ground wire with ring tong connector, that installs using one of the mounting screws, that holds the turn signal switch to your steering column. This makes a great ground, so you don't have to scrape on your new recreational vehicle steering column.
|
|
The LED Electronic Flasher is the key to the entire kit. After spending countless hours and using dozens of electronic flashers, I finally found the right one. This special LED electronic flasher is also quiet, no annoying clicking sounds.
I know now why there was no four light LED turn signal kit to be found, but there are some available NOW, at EZ Turn Signal Kits!
|
|
|
|
|
|
|
|
|
|
In Stock and Ready to Ship!
|
|
|
|
This is a 12 volt LED Turn Signal Kit with 2 Amber (front) and 2 Red (rear) LED lights. The 4 LED light kit comes with a turn signal switch, which has a pilot light for the turn signals and 4-way emergency flashers (hazard warning). The turn signal switch has a pull on flare tab for the 4-way hazard lights, an added 18" ground wire and the hardware to mount it to your steering column.
The 4 LED lights are 4x 2 rectangular with 16 (LED) Light Emitting Diodes each, polycarbonate lens & housing and hard wired with encapsulated electronics to eliminate corrosion.
The Special LED Electronic Flasher has the 3 pin connections for LOAD, PILOT and POWER. This special electronic LED flasher is also quite, no annoying clicking sounds.
The kit includes: 2 Amber and 2 Red LED lights, the Turn Signal Switch, an 18 ground wire with ring tong connector (for grounding the turn signal switch), the Special LED Electronic Flasher, an ATC in-line fuse holder, a 3 amp fuse and 9 screws for mounting the lights and flasher.
This kit can be easily installed, it does not go into any factory wiring, and it is a completely independent system that comes with the wiring diagram and instructions. Each wire has a different color and the wiring diagram shows where each colored wire goes. I include my phone number and e-mail address with the instructions, so if you have any questions about your installation you can contact me.
I supply the major quality components and hardware to mount them; you supply the color wire and connectors you want to use. This kit was originally developed for my Polaris Ranger and my customers have installed their kits on the Polaris Razor (RZR) and Crew, the Yamaha Rhino, the Arctic Cat Prowler, the Kawasaki Mule and Teryx, and the Cub Cadet Volunteer Tracker. This kit can be easily installed on any 12 volt Side-by-Side, UTV, Golf Cart, Bobcat, Kubota, Argo, Gator, Club Car, Sand Car, Dune Buggy, etc.
The local dealer charges $360 to install a kit with only 2 LED lights and 2 Bulb lights. You can install my 4 LED lights, turn signal switch, special LED electronic flasher, and save hundreds of dollars. This turn signal switch has been installed on thousands of units, very nice and easy to operate. The Motor Vehicle Department and your local police departments will be impressed. Everyone who rides on the street, off road, at the dunes or in congested riding areas, should have turn signals for there added safety.
|
|
|
Total Power Draw: .32 amps - that's less than a third of an amp with the four hazard lights on!
|
|
Non-Working Applications:
- 2009 Polaris Ranger HD or XP with tilt steering (turn signal switch will not mount on steering column).
Note: 2009 Polaris Ranger Crew and Razor work fine!
|
|
|
|
|
|
|
|
2 - Amber 4" x 2" LED Lights
2 - Red 4" x 2" LED Lights
1 - Turn Signal Switch w/hardware
1 - 18" Black Ground Wire (switch)
|
|
1 - LED Electronic Flasher
1 - In-line ATC Fuse Holder
1 - ATC Type 3 Amp Fuse
|
|
9 - Self Taping Screws for mounting
..... LED Lights & Electronic Flasher
Mounting Installation Instructions
Wiring Instructions & Diagram
|
|
|
|
Parts you supply: The color wire and connectors you want to use.
|
|
|
|

|
LED Parking Lights
& Turn Signal Kit
|
|
LED Parking Lights
& Turn Signal Kit
|
|
|
|
|
|
|
|
In Stock and Ready to Ship!
|
|
|
|
This is a 12 volt LED Parking Lights and Turn Signal Kit with 2 Amber (front) and 2 Red (rear) Dual Mode LED lights. The 4 Dual Mode LED light kit comes with a turn signal switch, which has a pilot light for the turn signals and 4-way emergency flashers (hazard warning). The turn signal switch has a pull on flare tab for the 4-way hazard lights, an added 18" ground wire and the hardware to mount it to your steering column.
The 4 Dual Mode LED lights are 4x 2 rectangular with 12 Colored (red or amber) Light Emitting Diodes each. They are chrome based, come with both clear & colored lenses and are hard wired with encapsulated electronics to eliminate corrosion. They have 3 lead wires each, one for ground, normal mode (parking lights) and high mode (turn signals), which is equal to 24 LEDs on high mode.
The Special LED Electronic Flasher has the 3 pin connections for LOAD, PILOT and POWER. This special electronic LED flasher is also quite, no annoying clicking sounds.
The Parking Light Switch is a LED illuminated rocker switch and is easy to install, vibration resistance, and will illuminate when turned on.
The kit includes: 2 Amber and 2 Red Dual Mode LED lights with both colored and clear lenses, the Turn Signal Switch, an 18 ground wire with ring tong connector (for grounding the turn signal switch), the Special LED Electronic Flasher, the LED illuminated rocker switch for parking lights, an ATC in-line fuse holder, a 3 amp fuse and 9 screws for mounting the lights and flasher.
This kit can be easily installed, it does not go into any factory wiring, and its a completely independent system that comes with the wiring diagram and instructions. Each wire has a different color and the wiring diagram shows where each colored wire goes. I include my phone number and e-mail address with the instructions, so if you have any questions about your installation you can contact me.
I supply the major quality components and hardware to mount them; you supply the color wire and connectors you want to use. This kit was originally developed for my Polaris Ranger and my customers have installed their kits on the Polaris Razor (RZR) and Crew, the Yamaha Rhino, the Arctic Cat Prowler, the Kawasaki Mule and Teryx, and the Cub Cadet Volunteer Tracker. This kit can be easily installed on any 12 volt Side-by-Side, UTV, Golf Cart, Bobcat, Kubota, Argo, Gator, Club Car, Sand Car, Dune Buggy, etc.
The local dealer charges $360 to install a kit with only 2 LED lights and 2 Bulb lights, and has NO parking lights. You can install my 4 Dual Mode LED lights, turn signal switch, special LED electronic flasher, LED illuminated rocker switch and save hundreds of dollars. This turn signal switch has been installed on thousands of units, very nice and easy to operate. The Motor Vehicle Department and your local police departments will be impressed. Everyone who rides on the street, off road, at the dunes or in congested riding areas, should have turn signals for there added safety.
|
|
|
Total Power Draw: .84 amps - that's less than an amp with the four parking and hazard lights on!
|
|
Non-Working Applications:
- 2009 Polaris Ranger HD or XP with tilt steering (turn signal switch will not mount on steering column).
Note: 2009 Polaris Ranger Crew and Razor work fine!
|
|
|
|
|
|
|
2 - Amber 4" x 2" Dual LED Lights
2 - Red 4" x 2" Dual LED Lights
1 - Turn Signal Switch w/hardware
1 - 18" Black Ground Wire (switch)
|
|
1 - LED Electronic Flasher
1 - In-line ATC Fuse Holder
1 - ATC Type 3 Amp Fuse
1 - LED Rocker Switch
|
|
9 - Self Taping Screws for mounting
..... LED Lights & Electronic Flasher
Mounting Installation Instructions
Wiring Instructions & Diagram
|
|
|
|
Parts you supply: The color wire and connectors you want to use.
|
|
|
|
|
|
|
|
Regular Bulb Turn Signal Kit
|
|
|
Regular Bulb Turn Signal Kit
|
|
|
|
|
|
|
|
In Stock and Ready to Ship!
|
|
|
|
This is a 12 volt Regular Bulb Turn Signal Kit with 2 Amber (front) and 2 Red (rear) lights. The 4 Regular Bulb light kit comes with a turn signal switch, which has a pilot light for the turn signals and 4-way emergency flashers (hazard warning). The turn signal switch has a pull on flare tab for the 4-way hazard lights, an added 18" ground wire and the hardware to mount it to your steering column.
The 4 Regular Bulb lights are 4x 2 rectangular with (2) bulbs each, they have two stainless steel grounds, corrosion-resistant contacts, lubricated fleet service bulbs, corrosion-proof body; they come with 4 extra ground wires and 8 self tapping screws for mounting.
The Flasher has the 3 pin connections for LOAD, PILOT and POWER. This flasher comes with a clamp and a self tapping screw for mounting.
The kit includes: 2 Amber and 2 Red Regular Bulb lights, 4 ground wires with ring tong connectors (for grounding the regular lights), the Turn Signal Switch with an 18 ground wire with ring tong connector (for grounding the turn signal switch), the Flasher with mounting clamp, an ATC in-line fuse holder, a 5 amp fuse and 9 self tapping screws for mounting the lights and flasher.
This kit can be easily installed, it does not go into any factory wiring, and it is a completely independent system that comes with the wiring diagram and instructions. Each wire has a different color and the wiring diagram shows where each colored wire goes. I include my phone number and e-mail address with the instructions, so if you have any questions about your installation you can contact me.
I supply the major quality components and hardware to mount them; you supply the color wire and connectors you want to use. My customers have installed their kits on the Polaris Ranger, Razor (RZR) and Crew, the Yamaha Rhino, the Arctic Cat Prowler, the Kawasaki Mule and Teryx, and the Cub Cadet Volunteer Tracker. This kit can be easily installed on any 12 volt Side-by-Side, UTV, Golf Cart, Bobcat, Kubota, Argo, Gator, Club Car, Sand Car, Dune Buggy, etc.
The local dealer charges $360 to install a kit. You can install my Regular Bulb Turn Signal Kit and save hundreds of dollars. This turn signal switch has been installed on thousands of units, very nice and easy to operate. The Motor Vehicle Department and your local police departments will be impressed. Everyone who rides on the street, off road, at the dunes or in congested riding areas, should have turn signals for there added safety.
|
|
|
Total Power Draw: 2.65 amps with the four hazard lights on!
|
|
Non-Working Applications:
- 2009 Polaris Ranger HD or XP with tilt steering (turn signal switch will not mount on steering column).
Note: 2009 Polaris Ranger Crew and Razor work fine!
|
|
|
|
|
|
|
2 - Amber 4" x 2" REG Bulb Lights
2 - Red 4" x 2" REG Bulb Lights
1 - Turn Signal Switch w/hardware
1 - 18" Black Ground Wire (switch)
|
|
1 - Regular Flasher
1 - In-line ATC Fuse Holder
1 - ATC Type 5 Amp Fuse
4 - 10" White Ground Wires
|
|
9 - Self Taping Screws for mounting
..... Regular Bulb Lights & Flasher
Mounting Installation Instructions
Wiring Instructions & Diagram
|
|
|
|
Parts you supply: The color wire and connectors you want to use.
|
|
|
|
|
|
|
|
|
|
|
|
|
